The Video camera system LUIS RV-Basic consists of a 7-inch flat screen, a color night vision rear view camera IP67 protection glass, and a salt water protected 20 meter cable. The mounting material is also included in this set.The high quality rear view camera is mirrored and has a viewing angle of 120 °.The modern night vision devices,permits the driver to even View in total darkness of the rear of his vehicle.

Monitor

Flat TFT Monitor
Display size: 7 "= approx 17cm
fast active matrix display
anti-reflective screen surface .
High resolution screen 1440 x 234 = 336 960 pixels
Brightness of 300cd / m²
Suitable for all video sources (rear view camera, TV, DVD, etc.)
2 Video Inputs
2 audio inputs
internal speaker
When connecting a reversing camera automatically switch the display
Horizontal and vertical mirror function possible
with stand
including 12V and 24V Power Cord
including cable
Size of the monitor: WxHxD = 179x119x23mm
Reversing camera

1/3 Sharp Sensor
Detection angle of 120 °
Color TV system with a resolution of 420 TV lines
good resolution 628 (H) × 582 (V) pixels
Total of 365 496 pixels
18 high power infrared LEDs for visibility in darkness TOP
Auto white balance
automatic light compensation
Sensitivity 0 Lux (IR ON)
special coating against corrosion
incl sunroof
including mounting feet
including cable entry
Mounting hardware included
Dimensions with stand Width: 72 / High 77 / Low: 52mm
Dimensions without bracket: Width: 68 / High 42 / Low: 52mm
Supply

Salt Festival universal cable set
20 meters long
1x video input
1x Audio Input
1x input for power supply
1x input / switching pulse reversing
1x Video Output
1x Audio Output

The rear view camera license plate LUIS T5 allows optimum visibility to the rear and is the perfect parking and reversing aid for vehicles of all kinds, the camera is easily integrated into a plate holder, which corresponds to the European standard.LUIS T5 license plate camera has night vision LEDs Your pictures then transmits on to the high-quality 3.5 inch color monitor.The presentation is on the monitor by means of auxiliary lines and precise information given in meters.It enables easy maneuvering in difficult situations.The rear view camera license plate LUIS T5 offers extremely high security with a 180° viewing angle.Auto LEDs ensure even in the dark optimal night vision.Due to the hermetically sealed case, the camera is protected from vandalism and weather conditions like snow, rain and direct sunlight The operating voltage of LUIS license plate camera is 12 volts.

For almost all vehicle models with European flag
20 meter cable for a trouble-free image
180 degree viewing angle
1 / 4 CCD Color Camera

technical data

License plate camera:
TV system: PAL
Resolution: PAL 512x 582 pixels
Horizental Sync. Frequency upward: 15.625KHz / 15 734 KHz
White Balance: Auto
Video Output: 1.0Vp-p, 75 ohms
Gamma: 0.45
Electronic shutter: 1 / 50 (PAL), 1 / 60 (NTSC) 1 / 10, 000 seconds
AGC: Auto
BLC: Auto
Power consumption: DC12 V
Operating temperature: -40 degrees to +80 degrees
180 degree viewing angle
Lens: 1.75 mm (P) / 1.75 mm (N), F = 2.5
Size: 530 x 136 x 40 mm

Monitor

Ultra-flat color monitor with Sharp Tft - Technology
Active Matrix
Screen size: 3.5 inches
Brightness of 300cd / m²
Resolution 1440 x 234 = 336 960 pixels
Elaborate anti-glare screen surface
High pixel accuracy
Compatible with all standard video sources such as TV, XBOX, PS2, DVD, video camera, digital camera, surveillance camera, etc.)


Certificates


IP68 dust-and waterproof
Directive 2003/97/EC
Long-term tested
Salt water resistant
E-marking
RoHs
FCC / C
